EHS-M2HE
Roll over image to zoom in
Call for Price
| Rated Voltage | 12–24 V DC 100–240 V AC |
|---|---|
| Audible Style | Pre-recorded alarms and melodies |
| Mounting | Bracket mount (included) |
| Body Color | Off-white |
| Volume | Up to 95 dB at 1 meter Adjustable from mute to max |
| Sound Storage | 32 sounds pre-installed (refer to specifications for details) |
| Channel Selection | - Bit Mode: 8 selectable channels via input signal - Binary Mode: 32 selectable channels via input signal |
| Conformity Standards | - UL 464 - CSA C22.2 No. 205-M1983 - FCC Part 15 Subpart B Class A - CE (DC models) - RoHS compliant |
| Protection Rating | IP65 |
| Remarks | - Sound volume control - 32 built-in tones - Choice of cable or terminal connection - Compatible with PNP/NPN input |
| Functions | 4.5G vibration resistance |
Product Features
- 30% smaller footprint compared to the EWH series for space-saving installation.
- Improved vibration resistance, tolerates up to 4.5G.
- Delivers high output sound pressure up to 110 dB at 1 meter, despite its compact size.
- Available with either pre-wired cable or screw terminal connection.
- Supports PNP and NPN transistor-based input signals.
- Compliant with the European RoHS Directive.
- Rated IP65 for dust and water resistance.
- Supports SD card for in-field melody customization.
- CE marking applies to DC-powered models.
